General Specifications
(Through applying 500VDC between impeller hub center and lead wire (+) )
(For models without PWM control function,there is no speed control wiring.)
Item No. | Operating Voltage |
Maximum Air Flow |
Maximum Air Pressure |
Rotational Speed |
Rate Current |
Input Power |
Noise | ||
(V) | (CMM) | (CFM) | (mmAq) | (inchAq) | (RPM) | (A) | (W) | dB(A) | |
CHA4012BL-A10(b) | 12 | 0.16 | 5.64 | 2.80 | 0.11 | 5800 | 0.04 | 0.48 | 23.31 |
CHA4012BM-A10(b) | 12 | 0.22 | 7.86 | 5.44 | 0.21 | 8000 | 0.10 | 1.20 | 30.29 |
CHA4012BH-A10(b) | 12 | 0.30 | 10.50 | 8.36 | 0.33 | 10000 | 0.20 | 2.40 | 35.14 |
CHA4012RL-A10(b) | 12 | 0.16 | 5.64 | 2.80 | 0.11 | 5800 | 0.04 | 0.48 | 23.31 |
CHA4012RM-A10(b) | 12 | 0.22 | 7.86 | 5.44 | 0.21 | 8000 | 0.10 | 1.20 | 30.29 |
CHA4012RH-A10(b) | 12 | 0.30 | 10.50 | 8.36 | 0.33 | 10000 | 0.20 | 2.40 | 35.14 |
